Growatt SPF 6000T 6.0kW Split Phase Off-Grid Storage Inverter | DVM-US MPV | Compatible with Growatt AXE LV Battery
- High yields: output power factor up to 1.0
- Low frequency inverter 120/240Vac Split Phase output
- Integrated MPPT charge controller
- Optional WIFI/ GPRS remote monitoring
- Built-in pure copper low frequency transformer
- Configurable grid or solar input priority
- WiFi dongle included
See the specs >
Product Overviews:
| Manufacturer | Growatt |
| Type | Grid-Off |
| Rated Power | 6.0kW |
| MPP Trackers | 3 |
| Max DC PV Input Current | 80A |
| Max DC PV Array Voltage | 250V |
| Max Efficiency | >97.5% |
| Warranty | 2 Years |
| Communication | ShineWiFi-F/ ShineGPRS-F |
Key Features:
-
Scalable & Flexible:
- Multi-customized modes for diverse scenarios
- Support Multiple power sources
PV, Battery, Diesel generator, and utility
- Compatible with lithium, lead-acid, and GEL batteries
-
High Yields:
- Output power factor up to 1.0
- 2 times peak power ability
- Dual voltage output
-
Smart & Reliable
- Support WiFi and GPRS Communication for remote monitoring
- PV keeper platform for local commissioning
- Built-in low-frequency transformer
Product Specifications:
Inverter Output
- Rated Power: 6.0kW
- Surge Rating: 18kW
- Inverter Efficiency(Peak): >85%
- Transfer Time 10ms( max )
AC Input
- Voltage: 240VAC
- Max Charging Current: 60A
Solar Charger
- Maximum PV Charge Current: 80A
- Maximum PV Array Power: 5.0kW
- Maximum PV Array Open Circuit Voltage: 250VDC
- MPPT Range@ Operating Voltage: 60~245VDC
- Maximum Efficiency : >97.5%
GENERAL DATA
- Dimensions(W*H*D): 14.17/21.26/8.58 inches( 360*650*218mm)
- Weight: 114.6lbs (52kg)
- Installation: Indoor, Wall-mount
- Protection Degree: IP20
Download
Datasheet
SPF 4000-12000T DVM-US MPV Datasheet
User Manual & Installation Quick Guide
SPF 4000~12000T DVM(DVM-MPV) User Manual
Certificate
SPF 4000-12000T DVM-US MPV UL1741
SPF_4000-6000T_DVM_CE_LVD
SPF_4000-6000T_DVM_CE_EMC
